What is E track rail clips?



Rail clip is a component of railway fastening systems. It is used to fix the railroad track to the underlying baseplate and sleepers. The clamping force by rail clips helps to maintain the gauge and prevent the rail from moving in the vertical and horizontal direction relative to the sleeper. One extensively used type of rail clip is an elastic rail clip made of hot-pressed spring steel. Its energy produced at elastic deformation can alleviate the vibration and shock when trains move. Other track materials such as rail joints, gauge rods, rail clamps, and rail pads are also available.



An E-type rail clip, also known as an elastic rail fastening or E-clip, is a spring-loaded fastening device that provides permanent elastic clamping for rail systems. These clips mount to sleepers using four coach screws and double spring washers, creating a secure yet flexible connection. The E-clip design provides a firm grip on the rail while allowing controlled movement and vibration absorption.





Model	Diameter	Material	Under Pressure	HRC	Weight
E1609	Ø 16mm	60Si2MnA	≥950kg	44-48	0.43kg/pc
E1809	Ø 20mm	60Si2MnA	≥950kg	44-48	0.61kg/pc
E1813	Ø 18mm	60Si2MnA	≥950kg	44-48	0.62kg/pc
E2001	Ø 20mm	60Si2MnA	≥950kg	44-48	0.80kg/pc
E2009	Ø 20mm	60Si2MnA	≥950kg	44-48	0.80kg/pc
E2039	Ø 20mm	60Si2MnA	≥950kg	44-48	0.80kg/pc
E2007	Ø 20mm	60Si2MnA	≥950kg	44-48	0.80kg/pc
E2055	Ø 20mm	60Si2MnA	≥950kg	44-48	0.80kg/pc
E2056	Ø 20mm	60Si2MnA	≥950kg	44-48	0.80kg/pc
E2063	Ø 20mm	60Si2MnA	≥950kg	44-48	0.80kg/pc





Frequently Asked Questions about e type rail tension clip



• What makes E-clips "elastic" compared to rigid fastening methods?



E-clips are manufactured from spring steel that flexes under load while maintaining consistent clamping force. This elasticity allows the clip to accommodate rail movement from thermal expansion and train passage while continuously applying downward pressure, unlike rigid spikes that can loosen over time.



• Are E-clips suitable for high-speed rail applications?



Yes, E-clips are widely used in high-speed rail systems due to their excellent vibration dampening and consistent clamping characteristics. Their ability to maintain proper rail positioning under dynamic loading makes them ideal for tracks experiencing speeds above 200 km/h where traditional rigid fasteners might fail.





• How much vertical rail movement do E-clips allow?



E-clips typically permit 3-5mm of controlled vertical rail movement under load. This engineered flexibility helps absorb impact forces while preventing excessive displacement that could compromise track geometry or cause passenger discomfort.



GNEE RAIL supplies E-clips, PR clip, SKL clips, Russia rail clip, Deenik clip, Nabla spring blade, KPO rail calmp, gantrex rail clips, fast clip, crane rail clip and other special clips for rails. We have proffesional production cline to design and manufacture standard rail clips or nonstandard clips. welcome to as.





download product catalog



Model	Diameter	Weight	Material
Type III	Ø18	0.80kg/pc	60Si2MnA
E1609	Ø16	0.43 kg/pc	60Si2MnA
E1809	Ø20	0.61kg/pc	60Si2MnA
E1813	Ø18	0.62kg/pc	60Si2MnA
E2001	Ø20	0.80kg/pc	60Si2MnA
E2007	Ø20	0.80kg/pc	60Si2MnA
E2009	Ø20	0.80kg/pc	60Si2MnA
E2039	Ø20	0.80kg/pc	60Si2MnA
E2055	Ø20	0.80kg/pc	60Si2MnA
E2056	Ø20	0.80kg/pc	60Si2MnA
E2063	Ø20	0.80kg/pc	60Si2MnA
PR85 Rail Clip	Ø13	0.25kg/pc	60Si2MnA
PR309A	Ø19	0.85kg/pc	60Si2MnA
PR401	Ø20	0.97kg/pc	60Si2MnA
PR415	Ø20	0.95kg/pc	60Si2MnA
PR601A	Ø20	1.03kg/pc	38Si7
SKL 1	Ø13	0.48kg/pc	60Si2CrA
SKL 3	Ø13	0.48kg/pc	60Si2CrA
SKL 12	Ø13	0.53kg/pc	38Si7
SKL 14	Ø13	0.53kg/pc	60Si2MnA
Special Rail Clip	Ø13	0.48kg/pc	60Si2MnA
Russia Rail Clip	Ø18	0.58kg/pc	60Si2MnA
Deenik Clip	Ø25	0.49-0.68kg/pc	60Si2MnA
Single Anti-	Ø20	0.25kg/pc	60Si2MnA
Theft
