What size are rail screw spikes
Sep 26, 2025
Railroad spike, also known as railway spike, track spikes, are designed with high precision and processed under mature technologies, which has been tested for decades.According to its features, we can classify it into two types, screw spike and dog spike. It has many different functions and can strength types of products.
Screw spike is also called sleeper screw, rail screw, through specific requirements such as length, diameter, drive head and thread profiles, the railway screw spikes can be classified into four types, including the Ss series sleeper screw, the square-head screw spike, the hexagon screw spike, and the double-head screw spike.
| Type | Ss5, Ss 8, Ss25, Ss36, UIC864-1 Series, etc |
| Raw material | Q235, 35 steel, 45steel, 40Mn2, 20 Mn Si |
| Grade | 4.6, 4.8, 5.6, 8.8 |
| Surface | plain(oiled), black paint, color paint, zinc, HDG, etc |
For more information – Get in touch now!
Ss series Sleeper Screw
| Type | Specification | Weight/kg | Surface | Standard |
| Ss 1/130 | M22*130 | 0.451 | Natural,Zinc,Paint,Oil. According to your needs. | UIC,AREMA,GB or According to your drawings or samples. |
| Ss 1/150 | M22*150 | 0.478 | ||
| Ss 2/180 | M22*150 | 0.595 | ||
| Ss 5/150 | M24*150 | 0.545 | ||
| Ss 6/150 | M26*150 | 0.702 | ||
| Ss 7/180 | M24*180 | 0.636 | ||
| Ss 8/140 | M24*140 | 0.528 | ||
| Ss 8/150 | M24*150 | 0.548 |
For more information – Get in touch now!
Square head screw spike
| Type | Specification | Material | Surface | Standard |
| Square head screw spike | M22*145 | 45# | Natural | UIC |
| 55Q | Zinc | AREMA | ||
| M22*155 | Q235 | Paint | DIN | |
| M22*165 | or | Oil | GB | |
| M22*185 | According to your needs. | According to your needs. | or | |
| M22*195 | According to your drawings or samples. | |||
| Other kinds |
For more information – Get in touch now!
Hexagon screw spike
| Grade | 4.6 | 5 .6 | 8.8 | 10.9 |
| Material | Q235 | 35# | 45# | 40Cr |
| Mechanical | Tensile strength: ≥ 400Mpa | Tensile strength: ≥ 500Mpa | Tensile strength: ≥ 800Mpa | Tensile strength: ≥ 1000Mpa |
| Yield strength: ≥ 240Mpa | Yield strength: ≥ 300Mpa | Yield strength: ≥ 640Mpa | Yield strength: ≥ 900Mpa | |
| Elongation: ≥ 22% | Elongation: ≥ 20% | Elongation: ≥ 12% | Elongation: ≥ 9% | |
| Cold bending: 90 degree | Cold bending: 90 degree | Cold bending: 90 degree | Cold bending: 90 degree | |
| without crack | without crack | without crack | without crack | |
| Surface | plain (oiled) , Oxide black, Zinc, HDG, wax, bitumen, Dacromet, Sherardizing | |||
For more information – Get in touch now!
Double-head screw spike
| Specifications |
| Size: 23×174 |
| Grade: 4.6, 5.6, 8.8, 10.9 |
| Raw Material: 35# |
| Raw material: Q235, 35#, 45# |
| Surface Treatment: Plain (oiled), Bluing, Zinc, HDG, etc |
